|Lift Capacity: 10,200 lb (4,600 kg)
|Diameter: 72" (1.83 m)
|Overall Height: 116" (2.95 m)
|Package Cube Dimensions: 41" x 41" x 8" (1.04cm x 1.04cm x 25cm)
|Weight: 105 lb (47 kg)
|When the U.S. Navy asked us to develop a flotation device that would dependably withstand particularly abusive conditions, SUBSALVE USA produced the 5-ton Deep Ocean Lift Bag, which has unprecedented strength, low elasticity and superior resistance to abrasion and chemical attack. It became our standard Professional Lift Bag design.
|Our most versatile and easy-to-use, these open-bottom, parachute-shaped lift bags with a single attachment point are essential in construction, heavy and light salvage and many offshore tasks
|“Inverted water droplet” design facilitates maximum lift capacity with least possible weight, with stress distributed evenly over the fabric surface.
|Equipped with all the necessary hardware and ready for immediate use.
|Each SUBSALVE USA lift bag is tested prior to shipping.
|Urethane-coated nylon—high-strength and heavy-duty
|Superior abrasion resistance
|Resistant to most petro-chemicals
|Low maintenance requirements and easy to clean
|RF welded seams
|Easy to use
|Proprietary Plunger Dump Valve – air control with push-button at top of bag and lanyard at bottom. Vent air from above, beside or below lift bag to achieve desired ascent rate as well as 1/4? NPT inflation port.
|Multiple nylon lift straps sewn directly to bottom of lift bag, which bears load and provides safe working ratio of 6:1.
|Fitted with a 3/4? NPT inflation port with quick disconnect or cam lock fitting and a 3/4? stainless steel ball valve for rapid deflation.
|Each SUBSALVE USA lift bag is tested prior to shipping
|All Subsalve USA products are compliant with IMCA D-016-AIRBAGS, ABS, U.S. Department of Defense Standards.
